Recommended Rider Height: 5'7" - 6'4" or 170cm - 195cm

Ⓐ - Total Length: 72.4" or 184cm
Ⓑ - Wheel Base: 49.2" or 125cm
Ⓒ - Seat Height: 34.3" or 87cm
Ⓓ - Handlebar Height: 44.5" or 113cm
Ⓔ - Rim Diameter: 24" or 57.5cm
Ⓕ - Standover: 27.2" or 69cm
Ⓖ - Reach Distance: 22.0" or 56cm
Ⓗ - Chain Stay Length: 22.0" or 56cm
Ⓘ - Seat Angle: No Actual Seatpost
Ⓙ - Seat Tube Length: No Actual Seat Tube
Ⓛ - Top Tube Length: No Actual Top Tube
Ⓜ - Bike Width: 28.7" or 73cm



Technical Specifications

*To ensure uninterrupted suppluying and shipping, some parts may differ from those listed.
Rest assured, our engineers rigorously test each component to guarantee quality and compatibility.

General Information

Top Speed

60 - 65 km/h for both pedal-assist and throttle.



Range per Charge

175 -320 km with PAS, or 95 - 105 km w/o PAS



Max Load

≤ 150 kg to ensure the performance and safety.



Rider Height

173 - 195 cm, or inseam ≥ 26.8".



Bike Weight

67 kg with the battery (15 kg) installed.



Ideal Use

IPX6 weather-proof, off-road / mountain / urban riding.

Riding with Unmatched Power



Battery Capacity

4,200 Watt·hour (60V 70Ah).



Cells Type

Lithium-ion pouch cells, Grade A.



Battery Lifespan

≥ 1200 charge cycles to 80% of capacity.



Motor Power

2,500W, or peak 2,600W.



Motor Torque

90 - 110 Newton·metre (max).



Motor Type

Brushless rear hub motor, IPX6.



PAS Levels

5 Levels with Cadence Sensor.



Throttle Type

5 Levels twist, slightly delayed response (safe design).



Display / Dashboard

Color LCD motors switch USB charge port.



Shifting Gears

Shimano 7s 14-28T, 44T chainring.



Battery Charger

67.2V 7A Quick charger, 8-10H charge time



Additional Modes

Cruise Control, 6 km/h Walk.

Biking Safely & Confidently



Brake System

Hydraulic disc brakes with motor cutoff.



Brake Rotors

Front 230mm (φ)  x 2.8mm (t), Rear 180mm (φ)  x 2.8mm (t) steel rotors.



Brake Caliper/Pads

4-Piston calipers with semi-metallic pads.



Bike Frame

High-carbon steel 20" x 15" frame.



Front Fork

Adjustable hydraulic suspension, 100mm travel.



Shock Absorber

FASTACE coil suspension, 50mm travel.



Head Light

2,000 Lumens (20W)  LED with built-in horn.



Tail Light

LED with integrated brake signal blinker.



Additinal Reflectors

Pedals, spokes, tires.



Tire Type

20" x 4.0" tires with tube (28-33 psi).



Saddle

Leather wide seat with memory foam.



Handlebar

Iron 710mm x 31.8mm (φ, center), rise

Components & Accessories



Bell

Electric horn built-in headlight.



Crankset

140mm Aluminum, 44T chainring w/ single-sided cover.



Pedals

WELLGO 16/9 aluminum alloy platform.



Derailleur

SHIMANO RD-TY300 7 speed.



Shifter

SHIMANO ASLTX50R7CT 22.2mm x 2400mm.



Freewheel / Cassette

SHIMANO MF-TZ500-7 14-28T.



Rims

36H aluminum alloy rims.



Spokes

Black stainless steel 12 Gauge.



Grips

120mm x 22.2mm (φ) rubber, anti-slip.



Seatpost

Aluminum seapost with 38.1mm clamp.



Headset

Integrated threadless headset.



Stem

31.8mm (φ, handlebar) * 35° A-head.



Kickstand

Aluminum alloy heavy-duty.



Racks & Baskset

Optional basket.



Fenders

Included plastic front and rear fenders.



Package List:

Electric Bike * 1 (85% assembled)
Battery * 1 (2 keys)
Battery Charger * 1
Front Wheel * 1
Headlight * 1
Pedals * 2 (left & right)
Screws & Toolkit * 1
Owner's Manual * 1



Riding Modes:5 Levels Pedal-Assist (Cadence)

5 Levels Throttle
8 Seconds Auto-Cruise
7-Speed Non-Electric
6 KM/H Walk
